FLAP TYPE TURNSTILE GATE MT224 – Ultra-Slim 120mm Body for Minimalist Spaces, Ultra-slim flap type turnstile with only 120mm cabinet depth. Fits narrow lobbies without sacrificing security. 0.3s fast open, 40 persons/min. Elegant minimalist design. Perfect for high-end retail & boutiques. Flap type Turnstile – Antimicrobial Coating for Healthcare & Food, Hygiene-focused flap barrier turnstile with silver-ion antimicrobial coating on all touch surfaces. Inhibits bacteria growth, easy to clean. Stainless steel, unique aesthetic. Perfect for hospitals & food factories.
Flap Type Turnstile – Adjustable Lane Width 550-900mm for Wheelchairs, Adaptable flap barrier turnstile with manually adjustable lane from 550mm to 900mm. Switch between standard access and wheelchair/luggage mode in seconds. 304 SS, unique design. Ideal for airports & hospitals. Bi-Directional Counter & Real-Time Occupancy Display, Smart flap barrier turnstile with ±99% accuracy bidirectional counting. Real-time occupancy data to LED screen or cloud. 304 stainless steel, sleek aesthetic. Perfect for museums, stadiums & retail stores.
Flap Type Turnstile – 2.2m High Transparent Extension for Open Feel, Combine our flap barrier turnstile with 2.2m tempered glass extension. Provides visual deterrence without claustrophobic feeling. 304 stainless steel, unique aesthetic. Perfect for corporate HQ & luxury retail. Open SDK/API for Custom Software Integration, Developer-friendly flap type turnstile with full SDK, API documentation. Customize access logic, ticketing, or attendance software. 304 stainless steel, sleek design. Ideal for system integrators & smart buildings.
We can provide OEM and ODM services. We have experienced designers who can complete deep customization according to any of your needs. We will provide a series of materials such as 3D renderings, dimensional drawings, etc. as soon as possible. Customizable Flap Barrier Turnstile – Swappable Brand Panels, Change your flap barrier turnstile’s look in seconds with swappable decorative panels. Wood, carbon fiber, colored acrylic, or etched logo. Unique design meets brand flexibility. OEM/ODM welcome.
All of our products carry a 2 years warranty and durable maintenance and repair support. We also provide biometric devices, such as fingerprint scanner, face recognition camera. RFID card reader, QR code scanner. If you need to integrate these devices on the turnstile gate or have any questions, please request a quote.
We can also create a rendering for you within a few minutes based on your actual scenario. We also provide detailed layout and drawings, as well as installation drawings. Let you have no worries about installation. Please download our corresponding PDF file for specific dimensions and installation dimensions.
Technical Parameter:
1. Size: 1200*300*980 mm (can be customized)
2. Lane width: 550 mm (can be customized)
3. Passing speed: 40 person/min
4. Power supply: 110V/220V 50/60Hz
5. Driving Motor: 20W
6. Gate Open Signal: Dry Contact/ Relay
7. Driving Motor: DC24V
8. Weight: 60 kg/pcs
9. Casing Material: 304 stainless steel
10. Reliability of the mechanism: 3 million, no-fault
11. Flap arm material: Acrylic
12. Blue PC arms are optional
13. LED lights on arms is available
14. Working Direction: Bidirectional/Single directional
15. Emergency situation: open automatically when the electricity is cut off with a capacitor
16. Humidity: ≤90％
17. Working temperature: -20℃～60℃
18. Communication distance: ≤1200 m
19. Communication interface: RS485
20. Feature: IC/ID reader, Barcode Reader, Face recognition, Fingerprint, other access control equipment, UPS, etc
21. Time needed for opening: 0.2 s
22. Working environment: Indoors
23. Application range: Community, Factory, Construction site, School, Place of the resort, etc
We can provide the entire security access control solution. If you have your own access control system, you can directly use our turnstile gate. If you don’t have one, we also provide a complete security access control solution. Please refer to the video below for details.
