Factory Direct Price | Global Delivery | Warranty 2 Years | OEM/ODM Service

Turnstile Gate: Security Turnstiles | Entrance Turnstile

Turnstile Factory – MairsTurnstile-Online


We can provide OEM and ODM services. We have experienced designers who can complete deep customization according to any of your needs. We will provide a series of materials such as 3D renderings, dimensional drawings, etc. as soon as possible.

All of our products carry a 2 years warranty and durable maintenance and repair support. We also provide biometric devices, such as fingerprint scanners, and face recognition cameras. RFID card reader, QR code scanner. If you need to integrate these devices on the turnstile gate or have any questions, please request a quote.

We can also create a rendering for you within a few minutes based on your actual scenario. We also provide detailed layout and drawings, as well as installation drawings. Let you have no worries about installation. Please download our corresponding PDF file for specific dimensions and installation dimensions.

Technical Parameter:

1.Size:1500*120*1000 mm (can be customized)
2. Lane Width: 600 mm (Standard) 1000mm(Max)
3. Arm material: 10 mm Acrylic
4. Passing speed: 40 person/min
5. Power supply: 110V/220V 50/60hz
6. Mechanism: Brushless motor
7. Gate Open Signal: 12V Dry Contact
8. Driving Motor: 24V
9. Weight: 90 kg/pcs
10. Size and material thickness can be customized
11. Casing Material: Cold-rolled sheet and aluminum alloy;
12. Aluminum alloy can be oxidized into various colors
13. Reliability of the mechanism: 3 million-5 million, no-fault
14. Working Direction: Bidirectional/Single directional
15. Emergency situation: open automatically when the electricity is cut off with a capacitor
16. Humidity: ≤90% No Condensation
17. Working temperature: -25℃~70℃
18. Communication distance: ≤1200 m
19. Communication interface: RS485
20. Feature: IC/ID reader, Barcode Reader, Face recognition, Fingerprint, other access control equipment, UPS, etc
21. Time needed for opening: 0.2 s
22. Working Environment: Indoors
23. Application range: Community, Office Building, School, Place of the resort, etc

We can provide the entire security access control solution. If you have your own access control system, you can directly use our turnstile gate. If you don’t have one, we also provide a complete security access control solution. Please refer to the video below for details.
