Turnstile Gate: Security Turnstiles | Entrance Turnstile

Turnstile Factory – MairsTurnstile-Online

We can provide OEM and ODM services. We have experienced designers who can complete deep customization according to any of your needs. We will provide a series of materials such as 3D renderings, dimensional drawings, etc. as soon as possible.

All of our products carry a 2 years warranty and durable maintenance and repair support. We also provide biometric devices, such as fingerprint scanner, face recognition camera. RFID card reader, QR code scanner. If you need to integrate these devices on the drop arm turnstile or have any questions, please request a quote.

We can also create a rendering for you within a few minutes based on your actual scenario. We also provide detailed layout and drawings, as well as installation drawings. Let you have no worries about installation. Please download our corresponding PDF file for specific dimensions and installation dimensions.

Technical  Parameter:

1. Size: 1400*280*980 mm (can be customized)
2. Lane width: 550 mm (can be customized)
3. Passing speed: 35 person/min
4. Power supply: 110V/220V
5. Weight: 60 kg
6. Input: Dry Contact
7.  Arm protective sleeve can be added
8.  Mechanism with hydraulic damper for shock absorbing
9. Casing Material: 304 stainless steel
10. Reliability of the mechanism: 3 million, no-fault
11. Power supply: AC110/220V ±10%
12. Solenoid valve: DC24V ±5%
13. Arm length: 510 mm
14. Direction of rotation: Bidirectional
15. Method of arm dropping: drop automatically when the electricity is cut off.
16. Operational voltage: DC 24V ±5%
17. Voltage of indicator light: DC12V ±5%(standard)
18. Working temperature: -30℃~60℃
19. Humidity: 5%~90%
20. Drop arm tripod turnstile Waterproof: IP56
21. Control interface: relay signal input
22. Time needed for opening: 0.2 s
23. Working environment: Indoor or outdoor
22. Application range: Community, Factory, Construction site, School, Place of the resort, etc
